12V 24V 36V 48V constant voltage strip light 70w led driver,triac dimmable 70w led driver

FOB Reference Price:Get Latest Price
50 Piece/Pieces NA (Min. Order)
Supply Ability:
10,000 Piece/Pieces per Month NA
Port:
shenzhen
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
HUEUC
Model Number:
DR-12V-4500-70D
Output Power:
51 - 100W
Output Type:
Single
Input Voltage:
110 / 220V
Output Voltage:
12V
Output Frequency:
50-60HZ
Output Current:
4300
Size:
123*79*35mm
Packaging & Delivery
Packaging Details
neutral packing or customized packing.
Delivery Time
7-10days after payment

Specifications

1)70w led driver
2) 12V triac dimmable led driver
3) 87% efficiency
4) PF 0.98
5)quality driver

  12V 24V 36V 48V constant voltage strip light 70w led driver,triac dimmable 70w led driver



Specification: CV 12V Version



Item No.:

DR-12V-4500-70D

Input Voltage(V/AC)

110 / 230V

Power:

50W

Output Voltage(V/DC)

12V

Output Current(mA)

4.3A

PF

>0.95

Efficiency

>80%

Dielectric Strength(V/AC)

3000

Size(mm)

123*79*35MM

Operation Temperature

-30~45 degree

Storage Temperature

-40~70 degree

Constant current precision

 5%

Thermal Dissipation

Nature

Relative Humidity

5~95%

Vibration

5-55hZ/2G,30Minutes

Life time

50000H,AT tc max





Specification: CV 24V Version



Item No.:

DR-24V-2100-70D

Input Voltage(V/AC)

110 / 230V

Power:

50W

Output Voltage(V/DC)

24V

Output Current(mA)

2.1A

PF

>0.95

Efficiency

>80%

Dielectric Strength(V/AC)

3000

Size(mm)

123*79*35MM

Operation Temperature

-30~45 degree

Storage Temperature

-40~70 degree

Constant current precision

 5%

Thermal Dissipation

Nature

Relative Humidity

5~95%

Vibration

5-55hZ/2G,30Minutes

Life time

50000H,AT tc max
